Mitox 28MT - Page 47

28MT Multi-Tool
47
Original Instructions Version June 16
28MTa_160616
Parts List - Hedgetrimmer
ID No. Part Number
Description
1 MIC26.1615.0100 RIGHT GEAR BOX ASSEMBLY
2 MIC26.1615.0103 POSITIONAL PLATE
3 MIGB/T97 M5 FLAT WASHER M5
4 MIGB/T93 M5 SPRING WASHER M5
5 MIGB/T2671.2 M5X16 SCREW M5X16
6 MIGB/T3452.1 34.5X1.8 O-RING 34.5X1.8
7 MIC26.1615.0201 LEFT GEAR BOX
8 MIGB6178 M6 NUT M6
9 MIGB91 2X14 COTTER PIN 2X14
10 MIC26.1615.0002 LEFT HALF HANDLE
11 MIC26.1615.0012 SMALL SPRING
12 MIC26.1615.0013 LARGE SPRING
13 MIGB/T2671.2 M5X20 SCREW M5X20
14 MIC26.1615.0001 RIGHT HAND HANDLE
15 MIGB/T119 B4X10 PIN B4X10
16 MIGB/T290 6X10X9 NEEDLE BEARNING
17 MIC26.1615.0005
SUBPLATE
18 MIC26.1615.0006 CONNECTING ROD
19 MIGB893.1 28 28 CIRCLIP
20 MIC26.1615.0202 GEAR BOX ASSEMBLY 2
21 MIGB/T3452.1 6X1.8 O-RING 6X1.8
22 MIGB/T97 M6 FLAT WASHER 6
23 MIGB/T2671.2 M6X12 SCREW M6X12
24 MIC26.1615.0107 SCREW
25 MIGB/T2671.2 M6X30 SCREW M6X30
26 MIGB/T93 M6 SPRING WASHER M6
27 MIC26.1615.0008 GEAR BOX ASSEMBLY 3
28 MIC26.1615.0004 SEALING GASKET
29 MIC26.1615.0003 GEAR BOX COVER
30 MIGB/T2672 M4X16 SCREW M4X16
31 MIC26.1615.0011 FELT SEALING GASKET
