Mitox 28MT - Page 50

28MT Multi-Tool
50
Original Instructions Version June 16
28MTa_160616
Parts List - Pole Pruner
ID No. Part Number
Description
1 MITBC431DJ.03.01-00 FRONT SHAFT ASSEMBLY
2 MIGB/T2671.2 M5X12 SCREW M5X12
3 MIC33.0614.0001 OIL TANK
4 MIC33.0614.0002 OIL CAP
5 MIC33.0614.0003 CHECK VALVE
6 MIC33.0614.0004 FUEL HOSE CONNECTOR
7 MIC33.0614.0005 OIL TUBE
8 MIC33.0614.0006 FUEL HOSE SPRING
9 MIC33.0614.0100 GEAR BOX ASSEMBLY
10 MIC33.0614.0004 FUEL HOSE CONNECTOR
11 MIC33.0614.0007 TENSION BLOCK
12 MIC33.0614.0008 SPRING
13 MIC33.0614.0009 TENSION SCREW
14 MIGB/T899 M6X30 DOUBLE END STUDS M6×30
15 MI100SDEA318 GUIDE BAR
16 MI91P040X SAW CHAIN
17 MIGB/T6177.1 M6 NUT M6
18 MIC33.0614.0010 SPROCKET COVER
19 MIGB/T2671.2 M6X16 SCREWM6X16
20 MIGB/T97.1 M6 PLATE WASHER 6
21 MIC33.0614.0011 SPROCKET 3/8"
22 MIC33.0614.0012 SLEEVE 12×17×4
23 MIC33.0614.0013 PANEL
24 MIC33.0614.0014 POSITIONAL IRON SHELF
25 MIGB/T 276 6001 BEARING 6001
26 MIGB/T2671.2 M6X8 SCREWM6X8
27 MIC33.0614.0015 SLEEVE12×17×7.7
28 MIC33.0614.0016 GUIDE SLEEVE
29 MIGB895.2 5 CLAMP
30 MIC33.0614.0017 PIN SPRING CIRCLIP
31 MIC33.0614.0018 PIN SPRING
