Mitox 331 - Technical Specifications

18
TECHNICAL SPECIFICATIONS
Above specifications are subject to change without notice.
MODEL MITOX 261
Type Air cooled 2-stroke petrol engine
Model IE34F-2E
Displacement : ( cm
3
) 25.4 cc
Max. output 0.7 (kw) in accordance with ISO 8893
Idle speed: rpm (min
–1
)
2800
±150
Max. power speed: rpm (min
–1
) 9800
Fuel tank capacity 0.65L
Fuel Mixture (Petrol 40 : Oil 1)
Carburetor Diaphragm type
Engine
Spark Plug NGK-R BPMR7A
Transmission Centrifugal clutch, spur gear, cam-crank
Fixation hole diameter: (mm) 26
Dry Weight w/o harness & gasoline 6.2 kg
Overall size (LxWxH) 1800mmx380mmx250mm
Reduction ratio 22 :17
3 teeth blade 255mm Cutting width
N
ylon head 415mm
3 teeth blade thickness 1.4mm
Cutting line diameter 2.5mm
Max. blade rotation speed: 7500 rpm (min
–1
)
Cutting head
Rotation direction Counter Clockwise(as seen from above)
MODEL MITOX 331
Type Air cooled 2-stroke petrol engine
Model IE36F-E
Displacement : ( cm
3
) 32.6 cc
Max. output 0.9 (kw) in accordance with ISO 8893
Idle speed: rpm (min
–1
)
2800
±150
Max. power speed: rpm (min
–1
) 10200
Fuel tank capacity 1 L
Fuel Mixture (Petrol 40 : Oil 1)
Carburetor Diaphragm type
Engine
Spark Plug NGK-R BPMR7A
Transmission Centrifugal clutch, spur gear, cam-crank
Fixation hole diameter: (mm) 26
Dry Weight w/o harness & gasoline 7.5kg
Overall size (LxWxH) 1800mmx630mmx390mm
Reduction ratio 22 :17
3 teeth blade 255mm Cutting width
Nylon head 415mm
3 teeth blade thickness 2.8mm
Cutting line diameter 2.5mm
Max. blade rotation speed: 7800 rpm (min
–1
)
Cutting head
Rotation direction Counter Clockwise(as seen from above)
