PROTECT THE ENVIRONMENT
Take used oil to an authorized collection point or follow the stipulations in the country where
the log splitter is used. Do not discharge into drains, soil or water.
MAINTAIN YOUR LOG SPLITTER WITH CARE
Always clean the unit after each use. Keep the log splitter clean for best and safest performance.
Follow instructions for lubricating. Inspect all hydraulic seals, hoses and couplers for leaks
prior to use. Control levers and power switch must be kept clean, dry and free from oil and
grease at all times.
MAKE THE WORKSHOP CHILDPROOF
Lock the workshop or garage. Store the log splitter away from children and others not
qualied to use it.
FOR YOUR SAFETY
Do not remove or tamper with any of the machine’s protection or safety devices or modify
the log splitter in any way.
TABLE OF CONTENTS
Safety Warnings & Cautions .….….….….….….….….….….….…………………………………………………………………..........2
Description of Product and Application Conditions.….….….….……………………………………………………………….…….....5
Specifications….….….……………………………….….….….….….………………………………………………..........5
Electrical Requirements .….….….….….….….….….….……………………………………………………………………………........5
Set up and Preparation for Operation…….……….….….….….….….….….….…………………………………………………….......6
Log Splitter Operation ...........…….….….….….….….….….….….….….………………………………………………………. ...................7
4 Way Cross Splitter…………………………….….….….….….….….….….….……………………………………………......…….7
Replacing Hydraulic Oil ……….….….….….….….….….….….………………......…………………………………………………....8
Sharpening Wedge ............…….….….….….….….….….….….….….………………….............……………………………………….....8
Trouble Shooting ………………….….….….….….….….….….….….……………………………………………….............………....9
Wiring Diagram ………………….….….….….….….….….….….………………………………….……………………………..........9
Plumbing Diagram …………………………….….….….….….….….….….….……………………………………………......…….9
Optional Workstand Assembly………………….….….….….….….….….….….……………………………………………......…….10
Parts Schematic .....…………….….….….….….….….….….….….….….….….……………………………...........................................................11
Declaration of Conformity .....…………….….….….….….….….….….….….….….….….…………………………….................................16
