DESCRIPTION OF MACHINE
The log splitter is designed to be used in a domestic application.
The log splitter is designed exclusively for the following applications:
-Splitting freshly cut timber that does not exceed the dimensions specied in the technical data.
The 4-way splitting cross is only to be used on freshly cut wood and not seasoned wood as this type of wood
can splinter and put undue strain on the log splitter.
APPLICATION CONDITIONS
This log splitter is designed to operate under ambient temperatures between +5ºC and 40ºC. It can be stored or transported under
ambient temperatures between -25ºC and 55ºC.
SPECIFICATIONS
Model Number LS45 LS55 LS55X
Motor 1500W 2200W 2200W
Log Capacity Diameter 50 ~ 250mm
Length 520mm
Maximum Force 4.5 Ton 5.5 Ton 5.5 Ton
Hydraulic Pressure 2320 PSI 2900PSI 2900PSI
Hydraulic Oil Capacity 3.5 L
Overall Sizes Length 940mm excluding optional stand
Width 270mm excluding optional stand
Height 510mm excluding optional stand
Weight 44kg 45kg 54.3kg
* The diameter of the log is a guide - a small log can be dicult to split when it has knots or a particularly tough bre. On the other
hand, it may not be dicult to split logs with regular bres even if their diameter exceeds the max. gure indicated above.
ELECTRICAL REQUIREMENTS
With a 230 Volt / 50Hz motor, the log splitter should be connected to a standard 230V+10% / 50Hz+1Hz. electrical supply as well as
a residual current device (RCD) with the maximum residual current Rated at 0.03A.
