2-1. UNIT CONSTRUCTION
Remote
controller
Name
Model number
Functions
M-NET remote controller
PAR-F27MEA-E, PAR-U02MEDA
• A handy remote controller for use in
conjunction
with the Melans centralized
management system.
• Addresses must be set.
• Addresses setting is not
necessary.
MA remote controller
PAR-21MAA, PAR-31/32MAA
*1
WhentheindoorunitofFreshAirtypeisconnectedwiththeoutdoorunit,themaximumconnectabletotalindoorunitcapacityis110%.
*2
PUMYisconnectabletoFreshAirtypeindoorunit.
Itispossibletoconnect1FreshAirtypeindoorunitto1outdoorunit.(1:1system)
 Operatingtemperaturerange(outdoortemperature)forfreshairtypeindoorunitsdifferfromotherindoorunits.
 Referto"2-4-(3).Operatingtemperaturerange".
*3
WhenconnectingtheCONNECTIONKIT(PAC-LV11M-J)andanM-seriesindoorunit,refertotheinstallationmanualfortheCONNECTIONKIT.
*
4
Do not connect Lossnay remote controller(s). (PZ-61DR-E, PZ-60DR-E, PZ-52SF-E, PZ-43SMF-E)
*5
Authorizedconnectableindoorunitsareasfollows;
PUMY-SP112:PEFY-P25VMA3-E×2 + PEFY-P32VMA3-E×2
PUMY-SP125: PEFY-P25VMA3-E×1 + PEFY-P32VMA3-E×3
PUMY-SP140: PEFY-P32VMA3-E×2 + PEFY-P40VMA3-E×2
*6
ForthePLFY-EP/VEM-E,upto2unitscanbeconnected.Otherindoorunits(ExcludingthePEFY-P/VMA3-EandPEFY-P/VMH-EF)can
beconnectedwithinthetotalratedcapacityandmaximumnumberofconnectedunits.
*7
ConnectableonlyforPUMY-SP▪VKMR1.TH(-BS),PUMY-SP▪YKMR1.TH(-BS).
OVERVIEW OF UNITS
Outdoor unit
4.5HP 5HP 6HP
PUMY-SP112VKM(R1).TH(-BS)
PUMY-SP112YKM(R1).TH(-BS)
PUMY-SP125VKM(R1).TH(-BS)
PUMY-SP125YKM(R1).TH(-BS)
PUMY-SP140VKM(R1).TH(-BS)
PUMY-SP140YKM(R1).TH(-BS)
Applicable
indoor unit
Capacity Type15toType140
Number of units 1to9units 1 to 10 units 1 to 12 units
Totalsystemcapacityrange 50to130%ofoutdoorunitcap50to130%ofoutdoorunitcapacity*
1
acity*250to130%ofoutdoorunitcapacity*2
Branching pipe
components
Branch header
(2 branches)
Branch header
(4 branches)
Branch header
(8 branches)
CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E
M series remote
controller
Model
Capacity
Cassette Ceiling
Ceiling
concealed
Wall
Mounted
Ceiling
Suspended
Floor standing Ceiling concealed
Lossnay
CONNECTION KIT
2 by 2 4-way ow 2-way ow 1-way ow Exposed Concealed Fresh air
*
2
Built-in
PAC-LV11M-J
PLFY-P PLFY-P
PLFY-EP*
6
PLFY-P PMFY-P PEFY-P PKFY-P PCFY-P PFFY-P PFFY-P PEFY-P PDFY-P GUF*
4
15
15VFM-E1 – – – – 15VMS1(L)-E 15VBM-E – – – – – –
20
20VFM-E1 20VEM-E – 20VLMD-E 20VBM-E
20VMS1(L)-E
20VMA(L)-E
20VMR-E-L/R
20VBM-E –
20VLEM-E
20VKM-E(2)
20VLRM-E
20VLRMM-E
– 20VM-E –
25
25VFM-E1 25VEM-E – 25VLMD-E 25VBM-E
25VMS1(L)-E
25VMA(L)-E
25VMR-E-L/R
25VMA3-E*
5
25VBM-E –
25VLEM-E
25VKM-E(2)
25VLRM-E
25VLRMM-E
– 25VM-E –
32
32VFM-E1 32VEM-E – 32VLMD-E 32VBM-E
32VMS1(L)-E
32VMA(L)-E
32VMR-E-L/R
32VMA3-E*
5
32VHM-E –
32VLEM-E
32VKM-E(2)
32VLRM-E
32VLRMM-E
– 32VM-E –
40
40VFM-E1 40VEM-E – 40VLMD-E 40VBM-E
40VMS1(L)-E
40VMA(L)-E
40VMH(S)-E
40VMA3-E*
5
40VHM-E 40VKM-E
40VLEM-E
40VKM-E(2)
40VLRM-E
40VLRMM-E
– 40VM-E –
50
50VFM-E1 50VEM-E 50VEM-E 50VLMD-E –
50VMS1(L)-E
50VMA(L)-E
50VMH(S)-E
50VHM-E – 50VLEM-E
50VLRM-E
50VLRMM-E
– 50VM-E 50RD(H)4
63
– 63VEM-E 63VEM-E 63VLMD-E –
63VMS1(L)-E
63VMA(L)-E
63VMH(S)-E
63VKM-E 63VKM-E 63VLEM-E
63VLRM-E
63VLRMM-E
– 63VM-E –
71
– – – – –
71VMA(L)-E
71VMH(S)-E
– – – – – 71VM-E –
80
– 80VEM-E 80VEM-E 80VLMD-E –
80VMA(L)-E
80VMH(S)-E
– – – – 80VMH-E-F 80VM-E –
100
– 100VEM-E – 100VLMD-E –
100VMA(L)-E
100VMH(S)-E
100VKM-E 100VKM-E – – – 100VM-E 100RD(H)4
125
– 125VEM-E – 125VLMD-E –
125VMA(L)-E
125VMH
(S) -E
– 125VKM-E – – – 125VM-E –
140
– – – – –
140VMA(L)-E
140VMH
(S) -E
– – – – 140VMH-E-F – –
M series indoor unit *
3
MSZ-GE Series
MSZ-SF Series
MSZ-EF Series
MSZ-FH Series
MSZ-LN Series
MSZ-AP Series *
7

Mitsubishi Electric City Multi PUMY-SP112YKM Specifications

General

Series	City Multi
Outdoor Unit Model	PUMY-SP112YKM
Cooling Capacity (kW)	11.2
Heating Capacity (kW)	12.5
Refrigerant	R410A
Operating Temperature Range (Cooling)	-5°C to 46°C
Power Source	380-415V, 50Hz
Operating Temperature Range (Heating)	-20°C to 15.5°C
Indoor Unit Compatibility	Various models in the City Multi series
