2Unpacking to installation
Confirming the products 2-7
CR760-D controller
1 Controller CR760-D 1 unit Stand alone type
2 Safety manual BFP-A8006 1 copy
3 CD-ROM (Instruction manual) 5F-FA01-C00 1 pc. Stand alone type
4 Dummy plug for T/B 2D-DP1 1 pc. Connect, when not using T/B.
5 Connector for EMG1 DFMC 1,5/12-ST-
3,5-LR
1 pc.
6 Connector for EMG2 DFMC 1,5/12-ST-
3,5-LR
1 pc.
7 Ferrite core E04SR301334 4 pc. For emergency stop wiring
8 1.6A fuse (reserves) LM16 1 pcs.
9 7.5A fuse (reserves) GP75 2 pcs.
10 Guarantee Card 1 copy
Note1) When the power cable (with the ACIN connector) is used, the ACIN connector and the ACIN terminal are not used.
When you build a power cable suitable for your environment, the ACIN connector and the ACIN terminal are used.
No. Part name Type Qty. Remarks
