Selection of operation mode and
operation location
(3) Controllability through communcation
*1 As set in Pr. 338 Communication operation command source and Pr. 339 Communication speed command source. (Refer to page 167)
*2 At occurrence of RS-485 communication error, the inverter cannot be reset from the computer.
*3 Enabled only when stopped by the PU. At a PU stop, PS is displayed on the operation panel. As set in Pr. 75
PU stop selection . (Refer to page 153)
*4 Some parameters may be write-disabled according to the Pr. 77
Parameter write selection setting and operating status. (Refer to page 155)
*5 Some parameters are write-enabled independently of the operation mode and command source presence/absence. When Pr. 77 = 2, write is
enabled. (Refer to page 59 for the parameter list)Parameter clear is disabled.
*6 When Pr. 550 NET mode operation command source selection = 1 (RS-485 terminals valid) or Pr. 550 NET mode operation command source selection = 9999 and the
communication option is not fitted.
*7 When Pr. 550 NET mode operation command source selection = 0 (communication option valid) or Pr. 550 NET mode operation command source selection
= 9999 and the communication option is fitted.
Operation
Location
Condition
(Pr. 551
Setting)
Operation
Mode
Item
PU
Operation
External
Operation
External/PU
Combined
Operation Mode
1
(
Pr. 79 = 3)
External/PU
Combined
Operation
Mode 2
(Pr. 79 = 4)
NET Operation
(when RS-485
terminals are
used)
*6
NET Operation
(when
communication
option is used)
*7
Control by RS-485 communication from PU connector
2
(PU
connector)
Run command (start) { ×× { ×
Run command (stop) { *3  *3 { *3
Running frequency
setting
{ × { ××
Monitor {{ { { {
Parameter write { *4 × *5 { *4 { *4 × *5
Parameter read {{ { { {
Inverter reset {{ { { {
Except for 2
Run command (start) ×× × × ×
Run command (stop)  *3  *3  *3  *3  *3
Running frequency
setting
×× × × ×
Monitor {{ { { {
Parameter write ×
*5 × *5 × *5 × *5 × *5
Parameter read {{ { { {
Inverter reset {{ { { {
Control by communication from
RS-485 terminals
1
(RS-485
terminals)
Run command(start,
stop)
{ ×× { ×
Running frequency
setting
{ × { ××
Monitor {{ { { {
Parameter write {
*4 × *5 { *4 { *4 × *5
Parameter read {{ { { {
Inverter reset {{ { { {
Except for 1
Run command
(start, stop)
×× × × { *1 ×
Running frequency
setting
×× × × { *1 ×
Monitor {{ { { { {
Parameter write ×
*5 × *5 × *5 × *5 { *4 × *5
Parameter read {{ { { { {
Inverter reset ×× × × {
*2 ×
Control by communication
from communication option

Run command
(start, stop)
×× × × × { *1
Running frequency
setting
×× × × × { *1
Monitor {{ { { { {
Parameter write × *5 × *5 × *5 × *5 × *5 { *4
Parameter read {{ { { { {
Inverter reset ×× × × × { *2
Control circuit
external terminals

Inverter reset {{ { { {
Run command
(start, stop)
× {{ ××
*1
Frequency setting × { × { × *1
{: Enabled, ×: Disabled,  : Some are enabled
