Mitsubishi Electric F700

229
Parameter copy and parameter verification
4
PARAMETERS
4.25.2 Parameter verification
appears...Why? Parameter read error. Perform operation from step 3 again.
appears...Why? Parameter write error. Perform operation from step 8 again.
and flicker alternately
Appears when parameters are copied between the inverter of
55K or less and 75K or more.
1. Set "0" in Pr. 160 User group read selection.
2. Set the following setting (initial value) in Pr. 989 Parameter copy alarm release.
3. Reset Pr. 9, Pr. 30, Pr. 51, Pr. 52, Pr. 54, Pr. 56, Pr. 57, Pr. 70, Pr. 72, Pr. 80, Pr. 90, Pr. 158, Pr. 190 to Pr. 196, Pr. 557,
Pr. 893.
Whether same parameter values are set in other inverters or not can be checked.
REMARKS
When the copy destination inverter is not the FR-F700 series, "model error ( )" is displayed.
flickers ... Why?
Set frequencies, etc. may be different. Check set frequencies.
55K or less 75K or more
Pr. 989 Setting 10 100
• Hold down to verify.
2.Screen at powering on
The monitor display appears.
Display
Operation
7.Press to read the parameter setting
of the verified inverter to the operation panel.
1.Replace the operation panel on the
inverter to be verified.
• Replace it during a stop.
Flicker ··· Parameter verification complete!!
4.Turn until (parameter copy)
appears.
6.Turn to change it to the set value
" "(parameter copy verification mode).
8.It there is no difference, and
flicker to complete verification.
The frequency flickers
for about 30s
Flickering
• If different parameters exist, different
parameter numbers and flicker.
The parameter
number read
previously appears.
5.Press to read the currently set
value.
" "(initial value) appears.
3.Press to choose the parameter
setting mode.
