Mitsubishi Electric F700 User Manual

171
Selection of operation mode and
operation location
4
PARAMETERS
(6) Switching of command source by external terminal (X67)
⋅ In network operation mode, the command source switching signal (X67) can be used to switch the operation
command source and speed command source. This signal can be utilized to control the signal input from both the
external terminal and communication.
⋅ Set "67" to any of Pr. 178 to Pr. 189 (input terminal function selection) to assign the X67 signal to the external
terminal.
⋅ When the X67 signal is off, the operation command source and speed command source are external.
X67 Signal State Operation Command Source Speed Command Source
No signal assignment
According to Pr. 338 According to Pr. 339
ON
OFF Operation is valid only from external terminal signal.
REMARKS
⋅ The ON/OFF state of the X67 signal is reflected only during a stop. It is reflected after a stop when the terminal is switched
during operation.
⋅ When the X67 signal is off, a reset via communication is disabled.
CAUTION
⋅ Changing the terminal assignment using Pr. 178 to Pr. 189 (input terminal function selection) may affect the other functions. Please
make setting after confirming the function of each terminal.
♦ Parameters referred to ♦
Pr. 28 Multi-speed input compensation selection Refer to page 88.
Pr. 59 Remote function selection Refer to page 89.
Pr. 79 Operation mode selection Refer to page 158.
