5.5.6 Pulse monitor
Various pulses can be monitored.
The setting is available when a vector control compatible option is installed.
Pulse monitor selection (Pr. 430)
● Shows the various pulse conditions during operation as the number of pulses.Set "0" in Pr. 52
"Operation panel main monitor selection" to display the output frequency monitor.
● If any of "26 to 31" is set in Pr. 52, Pr. 774 to Pr. 776, and Pr. 992, the electronic gear operation setting
for the pulse monitor by the multifunction monitor can be changed. (Refer to page 5-344.)
Pr. Name
Initial
value
Setting
range
Description
430
B011
Pulse monitor selection 9999
0 to 5, 12, 13,
100 to 105,
112, 113,
1000 to
1005, 1012,
1013, 1100
to 1105,
1112, 1113
Shows the various pulse conditions during operation
as the number of pulses.
8888, 9999 Shows the frequency monitor.
635
M610
Cumulative pulse clear
signal selection
00 to 3
Select the clearing method for the cumulative pulse
monitor.
636
M611
Cumulative pulse division
scaling factor
1 1 to 16384
Set the division scaling factor on the cumulative pulse
for the plug-in option (FR-A8AP).
637
M612
Control terminal option-
Cumulative pulse division
scaling factor
1 1 to 16384
Set the division scaling factor on the cumulative pulse
for the control terminal option (FR-A8TP).
638
M613
Cumulative pulse storage 0 0 to 3
Select the processing method for the cumulative
pulse monitor value when the power is turned OFF or
the inverter is reset.
Pr. 430 setting Description
첸첸첸0
Pulse monitor
selection
Displays the lower of the position command (accumulated value of command
pulses).
첸첸첸1
Displays the upper of the position command (accumulated value of command
pulses).
첸첸첸2
Displays the lower of the current position (accumulated value of feedback
pulses
).
첸첸첸3
Displays the upper of the current position (accumulated value of feedback
pulses
).
첸첸첸4 Displays the lower of the accumulated value of droop pulses.
첸첸첸5 Displays the upper of the accumulated value of droop pulses.
첸첸12
Displays the lower of the current position 2 (accumulated value of feedback
pulses
)
첸첸13
Displays the upper of the current position 2 (accumulated value of feedback
pulses
)
첸0첸첸
For pulse monitor
selection
Displays the monitor item selected in the pulse monitor selection after the
electronic gear operation.
첸1첸첸
Displays the monitor item selected in the pulse monitor selection before the
electronic gear operation.
Tab. 5-64: Pulse monitor selection (1)
