Outputs 6.
6-1
6. Outputs
6.1 Transistor output specification
Table 6.1 :
Switched voltage (resistive load)
5-30V DC
Rated current / N points
(resistive load)
FX
2NC
Main unit, Extension block:
0.1A/1point, 0.8A/8point, 0.3A/1point (Y000-Y003)
FX
0N
, FX
2N
Extension block:
0.5A/1point, 0.8A/4point, 1.6A/8point
Max. Inductive load
FX
2NC
Main unit, Extension block:
2.4W/24V DC, 7.2W/24V DC (Y000-Y003)
FX
0N
, FX
2N
Extension block:
12W/24V DC
Response time (approx.)
OFF
Æ
ON
<0.2ms (100mA/24V DC),
<15
µ
s (100mA/5V DC) (Y000,Y001)
ON
Æ
OFF
<0.2ms (100mA/24V DC),
<30
µ
s (100mA/5V DC) (Y000,Y001)
Open circuit current leakage
0.1mA/30V DC
Circuit isolation
Photocoupler
Operation indication
LED is lit when photocoupler is driven
FX2NC Series Programmable Controllers
