2 CPU MODULE FB
2.4 M+RCPU_MSynchronization_Delay1MOV, M+RCPU_MSynchronization_Delay2MOV
2.4 M+RCPU_MSynchronization_Delay1MOV,
M+RCPU_MSynchronization_Delay2MOV
Name
M+RCPU_MSynchronization_Delay1MOV, M+RCPU_MSynchronization_Delay2MOV
Overview
Labels
■Input labels
■Output label
Item Description
Functional overview Holds the value specified by transfer source data (input data) in the FB and executes the MOV instruction when the FB is
called next or the second time.
Symbol
No. Variable name Name Data type Range Default value Description
(1) i_bEN Execution
command
Bit On or off None On: FB starts.
Off: FB does not start.
(2) i_wData Transfer source
data
Word [signed] Effective device
range
None Specify the transfer source data or
the device containing the transfer
source data.
No. Variable name Name Data type Range Description
(3) o_wData Transfer
destination data
Word [signed] Effective device
range
Transfer data is stored.
B: i_bEN
o_wData: W
M+RCPU_MSynchronization_Delay2MOV
B: i_bEN
o_wData: W
W: i_wData
W: i_wData
M+RCPU_MSynchronization_Delay1MOV
(3)
(3)
(1)
(1)
(2)
(2)
