Mitsubishi Electric Mr.Slim PAR-40MAA User Manual

7. Restriction
Button operation
[
2
]
The current settings will appear.
Move the cursor to "Restriction" with the F1
or F2 button, and press
the SELECT
button.
The current settings will appear.
Move the cursor to "Temp. range" with the F1
or F2 button, and press
the SELECT
button.
[
1
]
Select "Energy saving" from the Main menu (refer to D-13), and press the
SELECT
button.
[
3
]
[
4
]
The screen to set the temperature range will appear.
Move the cursor to the desired item with the F1
button out of "Temp.
range", "Cool · Dry", "Heat" or "Auto."
7.1. Setting the temperature range restriction
Use to restrict the preset temprature range.
P
A006_new
Main Main menu
Energy saving
F1 F2 F3 F4
Temp. range
Select:
Cursor
Temp. range No / Yes
Cool·Dry
Heat
Auto
-
-
-
Cur.
Energy saving
Cursor
Restriction
Energy saving
Main menu:
F1 F2 F3 F4
Restriction
Setting display:
Page
Temp. range No
Cool·Dry
Heat
Auto
-
-
-
MA REMOTE CONTROLLER
6
. FUNCTION SETTINGS [PAR-40MAA]
D-29
MA REMOTE CONTROLLER
F1 F2 F3 F4
F1 F2 F3 F4
F1 F2 F3 F4
F1 F2 F3 F4

Mitsubishi Electric Mr.Slim PAR-40MAA Specifications

General

Model	PAR-40MAA
Brand	Mitsubishi Electric
Category	Remote Control
Type	Wired Remote Controller
Display	LCD
Compatibility	Mr.Slim Air Conditioners
Functions	Temperature, Fan Speed, Timer
Dimensions (H x W x D)	120 mm x 120 mm x 19 mm
Features	Energy Saving Mode
