Page 12
MODEL: WD-52327 / WD-62327
Accessing The Lamp Ballast
Removing the Right Support (Rear View)
1) Remove the Air Filter.
2) Remove the 3 screws (a).
3) Lift the upper cabinet slightly
to remove the support bracket.
Removing the Lamp Ballast Shield
(4 screws)
Unplug CJ3 & CN2
Connectors
4 Screws
Unplug
Connectors
(a)
Lift upper cabinet
slightly to remove
support.
Remove
Air Filter

Mitsubishi Electric WD-52327 Specifications

General

Screen Size	52 inches
Display Technology	DLP
Contrast Ratio	5000:1
Brightness	1200 ANSI Lumens
Aspect Ratio	16:9
Number of Speakers	2
Speakers	Built-in
Inputs	HDMI, Component, Composite, S-Video
Resolution	1920 x 1080 pixels
