Page 22
MODEL: WD-52327 / WD-62327
C. A/V Memory
Each of the external inputs has its’ own Audio/Video Memory. A change in an A/V setting at a specific input is
stored in memory for that specific input.
A/V Reset
1. The front panel AV Reset button initializes all A/V Memories.
2. The AV Reset in the user’s menu initializes only the selected input’s A/V Memory.
LED Indications
The three front panel LEDs provides an indication of the sets operation,
and the possible cause of a malfunction.
Function Ant -A/B DTV Comp-1/2 Input 1/2/3 MonoLink
Contrast Maximum Maximum Maximum Maximum Maximum
Brightness Center Center Center Center Center
Sharpness Center Center Center Center Center
Color Center Center Center Center Center
Tint Center Center Center Center Center
Color Temp. High High High High High
Video Noise Standard Standard Standard Standard Standard
Film Mode On On On On On
Bass Center Center Center Center Center
Treble Center Center Center Center Center
Balance Center Center Center Center Center
Surround Off Off Off Off Off
Listen To Stereo N/A N/A N/A N/A
Level Sound Off Off Off Off Off
A/V Memory Defaults
Normal LED Indications
Power/Timer Status Lamp Condition
Off Off Off Off (standby)
Green Blink Off Off µPC Initializing (after AC off/on) (1~2 sec)
Off Off Blink green Lamp Fan running (1 min after PTV Off)
Green Off Off Power On
Slow Green Blink Off Off Power On Timer is set.
Abnormal LED Indications
Power/Timer Status Lamp Condition
Off Yellow Off Temp. high - dirty filter/excess room temp.
Off Off Yellow 4000 hrs. Lamp usage warning
Off Off Blink Yellow Lamp Cover open
Off Blink Yellow Off Air Filter Cover open
Off Off Red Lamp failure (failed to turn On or broken)
Off Blink Red Off Fan Stopped
Red Off Circuit failure (short) or DVI cable disconnected
LED
LED
