MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-65638 / WD-73638 /
WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
ERROR CODES
Error Codes, descriptions and the most likely cause of failure are listed below:
ERROR CODE LOG (V43+ & V43++)
The Error Code Log may be helpful to retrieve the code for an error that occurred in the past.
Error Code Log Definitions
• PAGE - Current page number
• CURRENT TIME - total hours of operational
use.
• USAGE TIME - usage hours when the error
occurred.
• CODE - the specific Error Code that oc-
curred.
• STATUS: HAPPENED - Indicates an error
was recorded.
Press <CANCEL> to erase the Log.
NOTE: The Error Code Log is intended as a reference tool and
is not meant to be used as a final determination of a defective part.
Error Code Log
***** PAGE (001/001) *****
CURRENT TIME: 01455 HOURS
USAGE TIME CODE STATUS
00413 HRS 44 HAPPENED
00716 HRS 57 HAPPENED Press Up to Previous Page
Press Down to Next Page
Press Right to Top Page
Press Left to Last Page
Press CANCEL to Erase
Press MENU to Exit
<MENU><3-5-6-4>
ERROR CODES
Code Description Most Likely Cause
16 LAMP-EN Detection
Check Color Wheel / Check J6 & J7 circuitry /
Engine Failure
17 I2C Communication loss between TV Micro and Engine
Loss of 12V from PWB-POWER to Engine /
Check PE & PE2 circuitry
Engine Failure, PWB-MAIN Failure
18
Engine will not accept data
(ASIC-READY signal from Engine is not detected).
LDVS circuitry
Engine Failure
24 Sirocco fan (Lamp fan) rotation not detected. Check Sirocco Fan / Check J8 circuitry
36 Exhaust Fan rotation not detected. Check Exhaust Fan / Check J4 circuitry
37 Engine (DMD) fan rotation not detected. Check DMD Fan / Check J5 circuitry
44 LVDS cable between PWB-MAIN and Engine not detected. Check LVDS Cable & circuitry
48 PON-SHORT 3.3V or 5V switched supply short PWB-MAIN Failure
57 Ballast communication problem (ballast to chassis)
Loss of 340V from PWB-POWER to Ballast /
Check PL & CJ1 circuitry
Loss of communications between PWB-MAIN
and Ballast / Check FB & CJ3 circuitry
Ballast Failure
66
Lamp did not turn on at P-ON sequence
(No Lamp inserted)
(Disconnected cable between ballast and lamp)
(Lamp-Enable goes to PWB-MAIN but not to Ballast)
Check CJ4 circuitry
No Lamp Inserted.
HV connection or lead wire to lamp.
Lamp Cartridge Failure
34
Lamp turns Off while the TV is playing.
Lamp Failure
Lamp Enable signal from engine is lost.
Lamp Cartridge Failure
