2 SELECTION DATA
2.1 Specifications
Model SRK06CC-1, -4 (Indoor unit)
SRC06CC-1, -4 (Outdoor unit)
(2) The operation data are applied to the 220/240 V districts respectively.
(3) The refrigerant quantity to be charged includes the refrigerant in 10 m connecting piping.
(Purging is not required even in the short piping.)
If the piping length is longer, when it is 10 to 15 m, add 20 g refrigerant per meter.
(4) Expressed in sound pressure level.
Notes (1) The data are measured at the following conditions.
Item
Model
SRK06CC-1, -4 SRC06CC-1, -4
Cooling capacity
(1)
W 1800
Power source 1 Phase, 220/240V, 50Hz
Cooling input kW 0.93
Running current (Cooling) A 4.3/4.6
Inrush current A 18.2
COP (In cooling) 1.93
Noise level
(4)
dB (A) 40 54
Exterior dimensions
mm 250 × 750 × 178 540 × 645 × 245
Height × Width × Depth
Color Ivory white Polar white
Net weight kg 7.5 26
Refrigerant equipment
–
RM5512GNE1 (Rotary type) × 1
Compressor types & Q’ty
Motor kW – 0.75
Starting method – Line starting
Heat exchanger Louver fins & tubing
Refrigerant control Capillary tubes
Refrigerant
(3)
kg R22 0.63 (Pre-Charged up to the piping length of 10m)
Refrigerant oil R 0.35 (BARREL FREEZE 32SAM)
Air handling equipment
Tangential fan × 1 Propeller fan × 1
Fan type & Q’ty
Motor W 17 20
Air flow (at High) CMM 6.5 21
Air filter, Q’ty Polypropylene net (washable) × 2–
Shock & vibration absorber – Cushion rubber (for compressor)
Electric heater ––
Operation control
Wireless-Remote controller –
Operation switch
Room temperature control MC. Thermostat –
Pilot lamp RUN (Green), TIMER (Yellow) –
Safety equipment
–
Dome mounted protector (for compressor)
Internal thermostat (for fan motor)
O.D mm (in) Liquid line: ø6.35 (1/4") Gas line: ø9.52 (3/8")
Connecting method Flare connecting
Attached length of piping Liquid line: 0.4 m
–
Gas line : 0.35 m
Insulation Necessary (Both sides)
Drain hose Connectable
Power source cord 3 m (3 cores)
Size × Core number 1.5 mm
2
× 2 cores
Connecting method Terminal block (Screw fixing type)
Accessories (included) Mounting kit
Optional parts –
Connection
wiring
Operation
data
(1)
Refrigerant
piping
Item Indoor air temperature Outdoor air temperature
Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°C ISO-T1, JIS C9612
