36
-
(2) The operation data are applied to the 220/240 V districts respectively.
(3) The refrigerant quantity to be charged includes the refrigerant in 7.5 m connecting piping.
(Purging is not required even in the short piping.)
If the piping length is longer, when it is less than 10 m, add 10 g refrigerant per meter and when it is 10 to 15 m, add 30 g refrigerant per meter.
(4) Expressed in sound pressure level.
Notes (1) The data are measured at the following conditions.
Item
Model
SRK12CC-1, -4 SRC12CC-1, -4
Cooling capacity
(1)
W 3500
Power source 1 Phase, 220/240V, 50Hz
Cooling input kW 1.38
Running current (Cooling) A 6.4/6.8
Inrush current A 33.6
COP (In cooling) 2.53
Noise level
(4)
dB (A) 43 51
Exterior dimensions
mm 275 × 790 × 174 542 × 795 × 255
Height × Width × Depth
Color Ivory white Polar white
Net weight kg 8 37
Refrigerant equipment
–
RM5517GNE4 (Rotary type) × 1
Compressor types & Q’ty
Motor kW – 1.3
Starting method – Line starting
Heat exchanger Louver fins & tubing
Refrigerant control Capillary tubes
Refrigerant
(3)
kg R22 1.3 (Pre-Charged up to the piping length of 7.5m)
Refrigerant oil R 0.6 (BARREL FREEZE 32SAM)
Air handling equipment
Tangential fan × 1 Propeller fan × 1
Fan type & Q’ty
Motor W 16 18
Air flow (at High) CMM 8.5 22
Air filter, Q’ty Polypropylene net (washable) × 2–
Shock & vibration absorber – Cushion rubber (for compressor)
Electric heater ––
Operation control
Wireless-Remote controller –
Operation switch
Room temperature control MC. Thermostat –
Pilot lamp RUN (Green), TIMER (Yellow) –
Safety equipment
–
Dome mounted protector (for compressor)
Internal thermostat (for fan motor)
O.D mm (in) Liquid line: ø6.35 (1/4") Gas line: ø12.7 (1/2")
Connecting method Flare connecting
Attached length of piping Liquid line: 0.44 m
–
Gas line : 0.39 m
Insulation Necessary (Both sides)
Drain hose Connectable
Power source cord 2.5 m (3 cores with Earth)
Size × Core number 1.5 mm
2
× 2 cores
Connecting method Terminal block (Screw fixing type)
Accessories (included) Mounting kit
Optional parts –
Connection
wiring
Operation
data
(1)
Refrigerant
piping
Item Indoor air temperature Outdoor air temperature
Standards
Operation DB WB DB WB
Cooling 27°C19°C35°C24°C ISO-T1, JIS C9612
Model SRK12CC-1, -4 (Indoor unit)
SRC12CC-1, -4 (Outdoor unit)
