Mitsubishi 10 - Electrical Data

- 9 -
ELECTRICAL DATA
Heating
VOLT ITEM
PR-5YC
PRH-5YA
PRH-5YA-L
PR-8YC
PRH-8YA
PRH-8YA-L
PR-10YC
PRH-10YA
PRH-10YA-L
PR-15YC
PRH-15YA
PRH-15YA-L
PR-20YC
PRH-20YA
PRH-20YA-L
TOTAL INPUT kW 5.4 8.3 11.4 16.8 22.7
TOTAL RUN CURRENT A 10.3 15.9 20.2 30.8 39.1
POWER FACTOR % 73 73 79 76 81
START CURRENT A 62 87 100 115 135
415V COMPRESSOR INPUT kW 3.92 6.46 9.22 2 X 6.55 2 X 9.30
RUN CURRENT A 7.44 11.70 15.62 2 X 11.74 2 X 15.22
I/D FAN INPUT kW 1.24 1.30 1.64 2.62 3.02
RUN CURRENT A 2.26 2.90 3.28 4.72 6.06
O/D FAN INPUT kW 0.24 0.54 0.54 2 X 0.54 2 X 0.54
RUN CURRENT A 0.6 1.3 1.3 2 X 1.3 2 X 1.3
TOTAL INPUT kW 5.4 8.3 11.4 16.8 22.7
TOTAL RUN CURRENT A 11.2 17.3 21.9 33.6 42.6
POWER FACTOR % 73 73 79 76 81
START CURRENT A 68 95 109 126 147
380V COMPRESSOR INPUT kW 3.92 6.46 9.22 2 X 6.55 2 X 9.30
RUN CURRENT A 8.06 12.71 16.90 2 X 12.80 2 X 16.57
I/D FAN INPUT kW 1.24 1.30 1.64 2.62 3.02
RUN CURRENT A 2.48 3.17 3.58 5.16 6.62
O/D FAN INPUT kW 0.24 0.54 0.54 2 X 0.54 2 X 0.54
RUN CURRENT A 0.66 1.42 1.42 2 X 1.42 2 X 1.42
Cooling
VOLT ITEM
PRH-5YA
PRH-5YA-L
PRH-8YA
PRH-8YA-L
PRH-10YA
PRH-10YA-L
PRH-15YA
PRH-15YA-L
PRH-20YA
PRH-20YA-L
TOTAL INPUT
kW 4.8 7.0 9.6 14.4 19.3
TOTAL RUN CURRENT
A 9.8 14.1 18.2 27.2 34.8
POWER FACTOR
%6869737477
START CURRENT
A 62 87 100 111 131
415V COMPRESSOR INPUT kW 3.32 5.16 7.42 2 X 5.35 2 X 7.60
RUN CURRENT A 6.94 9.90 13.62 2 X 9.94 2 X 13.07
I/D FAN INPUT kW 1.24 1.30 1.64 2.62 3.02
RUN CURRENT A 2.26 2.90 3.28 4.72 6.06
O/D FAN INPUT kW 0.24 0.54 0.54 2 X 0.54 2 X 0.54
RUN CURRENT A 0.6 1.3 1.3 2 X 1.3 2 X 1.3
TOTAL INPUT
kW 4.8 7.0 9.6 14.4 19.3
TOTAL RUN CURRENT
A 10.7 15.4 20.0 29.6 38.1
POWER FACTOR
%6869737477
START CURRENT
A 68 95 109 121 143
380V COMPRESSOR INPUT kW 3.32 5.16 7.42 2 X 5.35 2 X 7.60
RUN CURRENT A 7.56 10.81 15.00 2 X 10.8 2 X 14.32
I/D FAN INPUT kW 1.24 1.30 1.64 2.62 3.02
RUN CURRENT A 2.48 3.17 3.58 5.16 6.62
O/D FAN INPUT kW 0.24 0.54 0.54 2 X 0.54 2 X 0.54
RUN CURRENT A 0.66 1.42 1.42 2 X 1.42 2 X 1.42
(PRH,PRH-L Only)
