Mitsubishi 10 - Refrigerant Schematics; PR-5 YC Schematic; PR-8, 10, 15, 20 YC Schematic

- 45 -
REFRIGERANT SCHEMATICS
Dryer
Strainer
Check
joint
ø19.05
Capillary
Tube
Check
joint
ø12.7
ø22.2
ø12.7
Check
joint
Check
joint
Pressure
gauge
High
pressure
switch
Compressor
Condenser
Evaporator
ø12.7
ø19.05
: OPTION
PR-5YC
Dryer
Strainer
Check
joint
ø19.05
Capillary
Tube
Check
joint
ø12.7
ø22.2
ø12.7
Check
joint
Check
joint
Pressure
gauge
High
pressure
switch
Compressor
Condenser
Evaporator
ø12.7
ø19.05
: OPTION
PR-8, 10, 15, 20YC
Notes: This schematics shows one refrigerant cycle.
PR-15,20YC or PRH-15,20YA or PRH-15,20YA-L is
composed of two refrigerant cycles.
