Mitsubishi 10 User Manual

OUTDOOR DB ˚C
INDOOR INDOOR 20.0 25.0 30.0 35.0 40.0 46.0
DB ˚C WB ˚C Q kW SHC kW SHF T/I kW Q kW SHC kW SHF T/I kW Q kW SHC kW SHF T/I kW Q kW SHC kW SHF T/I kW Q kW SHC kW SHF T/I kW Q kW SHC kW SHF T/I kW
15 16.4 11.3 0.69 4.5 15.8 11.1 0.70 4.7 15.2 10.8 0.71 4.9 14.5 10.4 0.72 5.1 13.8 10.1 0.73 5.4 13.0 9.8 0.75 5.7
20 16 16.9 10.3 0.61 4.6 16.3 10.1 0.62 4.8 15.6 9.8 0.63 5.0 15.0 9.6 0.64 5.2 14.2 9.2 0.65 5.5 13.3 8.9 0.67 5.8
17 17.4 9.4 0.54 4.6 16.8 9.1 0.54 4.8 16.1 8.9 0.55 5.0 15.4 8.5 0.55 5.3 14.7 8.2 0.56 5.5 13.7 7.8 0.57 5.8 15 16.4 13.1 0.80 4.5 15.8 12.8 0.81 4.7 15.2 12.5 0.82 4.9 14.5 12.2 0.84 5.1 13.8 11.9 0.86 5.4 13.0 11.6 0.89 5.7 16 16.9 12.2 0.72 4.6 16.3 11.9 0.73 4.8 15.6 11.5 0.74 5.0 15.0 11.4 0.76 5.2 14.2 11.1 0.78 5.5 13.3 10.6 0.80 5.8
22 17 17.4 11.1 0.64 4.6 16.8 10.9 0.65 4.8 16.1 10.6 0.66 5.0 15.4 10.3 0.67 5.3 14.7 10.1 0.69 5.5 13.7 9.7 0.71 5.8
18 17.9 10.2 0.57 4.7 17.3 10.0 0.58 4.9 16.6 9.8 0.59 5.1 15.9 9.4 0.59 5.3 15.1 9.1 0.60 5.6 14.2 8.8 0.62 5.9 19 18.5 9.4 0.51 4.7 17.8 9.1 0.51 4.9 17.1 8.9 0.52 5.2 16.3 8.5 0.52 5.4 15.6 8.3 0.53 5.7 14.6 7.9 0.54 6.0 16 16.9 14.0 0.83 4.6 16.3 13.7 0.84 4.8 15.6 13.4 0.86 5.0 15.0 13.2 0.88 5.2 14.2 12.8 0.90 5.5 13.3 12.5 0.94 5.8 17 17.4 13.1 0.75 4.6 16.8 12.8 0.76 4.8 16.1 12.4 0.77 5.0 15.4 12.2 0.79 5.3 14.7 11.9 0.81 5.5 13.7 11.5 0.84 5.8
24 18 17.9 12.2 0.68 4.7 17.3 11.9 0.69 4.9 16.6 11.6 0.70 5.1 15.9 11.3 0.71 5.3 15.1 11.0 0.73 5.6 14.2 10.7 0.75 5.9
19 18.5 11.1 0.60 4.7 17.8 10.9 0.61 4.9 17.1 10.6 0.62 5.2 16.3 10.3 0.63 5.4 15.6 10.0 0.64 5.7 14.6 9.6 0.66 6.0 20 19.0 10.1 0.53 4.8 18.3 9.7 0.53 5.0 17.6 9.5 0.54 5.2 16.8 9.2 0.55 5.5 16.0 9.0 0.56 5.8 15.0 8.6 0.57 6.1 21 19.5 9.2 0.47 4.8 18.8 8.8 0.47 5.1 18.0 8.6 0.48 5.3 17.3 8.5 0.49 5.6 16.4 8.2 0.50 5.9 15.4 7.9 0.51 6.2 18 17.9 14.0 0.78 4.7 17.3 13.7 0.79 4.9 16.6 13.4 0.81 5.1 15.9 13.2 0.83 5.3 15.1 12.8 0.85 5.6 14.2 12.5 0.88 5.9 19 18.5 13.0 0.70 4.7 17.8 12.6 0.71 4.9 17.1 12.3 0.72 5.2 16.3 12.1 0.74 5.4 15.6 11.9 0.76 5.7 14.6 11.4 0.78 6.0
26 20 19.0 12.0 0.63 4.8 18.3 11.7 0.64 5.0 17.6 11.4 0.65 5.2 16.8 11.1 0.66 5.5 16.0 10.7 0.67 5.8 15.0 10.4 0.69 6.1
21 19.5 10.9 0.56 4.8 18.8 10.7 0.57 5.1 18.0 10.4 0.58 5.3 17.3 10.2 0.59 5.6 16.4 9.8 0.60 5.9 15.4 9.5 0.62 6.2 22 20.1 10.1 0.50 4.9 19.3 9.7 0.50 5.1 18.5 9.4 0.51 5.4 17.7 9.2 0.52 5.7 16.9 9.0 0.53 6.0 15.9 8.6 0.54 6.3 23 20.7 9.1 0.44 4.9 19.9 8.8 0.44 5.2 19.1 8.6 0.45 5.5 18.3 8.2 0.45 5.8 17.4 8.0 0.46 6.1 16.4 7.5 0.46 6.4 19 18.5 14.8 0.80 4.7 17.8 14.4 0.81 4.9 17.1 14.2 0.83 5.2 16.3 13.9 0.85 5.4 15.6 13.6 0.87 5.7 14.6 13.1 0.90 6.0 20 19.0 13.7 0.72 4.8 18.3 13.4 0.73 5.0 17.6 13.2 0.75 5.2 16.8 12.8 0.76 5.5 16.0 12.5 0.78 5.8 15.0 12.2 0.81 6.1
28 21 19.5 12.9 0.66 4.8 18.8 12.6 0.67 5.1 18.0 12.2 0.68 5.3 17.3 11.9 0.69 5.6 16.4 11.6 0.71 5.9 15.4 11.2 0.73 6.2
22 20.1 11.9 0.59 4.9 19.3 11.6 0.60 5.1 18.5 11.3 0.61 5.4 17.7 11.0 0.62 5.7 16.9 10.6 0.63 6.0 15.9 10.3 0.65 6.3 23 20.7 11.0 0.53 4.9 19.9 10.5 0.53 5.2 19.1 10.3 0.54 5.5 18.3 10.1 0.55 5.8 17.4 9.7 0.56 6.1 16.4 9.3 0.57 6.4 24 21.4 10.1 0.47 5.0 20.6 9.7 0.47 5.3 19.8 9.5 0.48 5.6 18.9 9.1 0.48 5.9 18.0 8.8 0.49 6.2 16.8 8.4 0.50 6.5 20 19.0 15.6 0.82 4.8 18.3 15.2 0.83 5.0 17.6 15.0 0.85 5.2 16.8 14.6 0.87 5.5 16.0 14.2 0.89 5.8 15.0 14.0 0.93 6.1 21 19.5 14.6 0.75 4.8 18.8 14.3 0.76 5.1 18.0 14.0 0.78 5.3 17.3 13.8 0.80 5.6 16.4 13.4 0.82 5.9 15.4 13.1 0.85 6.2
30
22 20.1 13.7 0.68 4.9 19.3 13.3 0.69 5.1 18.5 13.0 0.70 5.4 17.7 12.7 0.72 5.7 16.9 12.5 0.74 6.0 15.9 12.1 0.76 6.3 23 20.7 12.6 0.61 4.9 19.9 12.3 0.62 5.2 19.1 12.0 0.63 5.5 18.3 11.9 0.65 5.8 17.4 11.7 0.67 6.1 16.4 11.3 0.69 6.4 24 21.4 11.8 0.55 5.0 20.6 11.5 0.56 5.3 19.8 11.3 0.57 5.6 18.9 11.0 0.58 5.9 18.0 10.6 0.59 6.2 16.8 10.2 0.61 6.5
PR-5YC PRH-5YA PRH-5YA-L
AIR VOLUME
CMM 45 50 55 60
L/S 750 830 920 1,000
COOLING
CAPACITY 0.975 0.988 1.0 1.013 TOTAL INPUT 0.987 0.994 1.0 1.005
OPERATION RANGE
PR-5YC PRH-5YA-L PRH-5YA
- 10 -
CAPACITY TABLES
Cooling Capacity (Nominal Air Flow):PR-5YC, PRH-5YA, PRH-5YA-L
Note1. * Q :COOLING CAPACITY SHC:SENSIBLE HEAT CAPACITY T/I:TOTAL INPUT
Factor for Various Air Flow
