ACCESSORY AVAILABILITY
SAFETY & CONTROL DEVICES
ITEM NO.
COMPRESSOR OVER CURRENT RELAY 51C1,2 27.5A 31.0A
COMPRESSOR INTERNAL THERMOSTAT - 120
˚C OFF 130 ˚C OFF
HIGH PRESSURE SWITCH 63H1,2 2.94MPa OFF
FREEZE PROTECTOR 26L1,2 -2
˚C IN
FROST PROTECTOR
(ONLY PRH-YA,PRH-YA-L) 26D1,2,3,4 -12 ˚C IN, 6 ˚C OUT
INDOOR FAN MOTOR OVER CURRENT RELAY 51F1 5.0A 6.6A
OUTDOOR FAN MOTOR OVER CURRENT RELAY 51F2,3 2.0A
OUTDOOR FAN MOTOR INTERNAL THERMOSTAT - 150
˚C OFF
FUSE (CONTROL CIRCUIT) F 3.15A
FUSE (OPERATION CIRCUIT) F 3.15A
OUTDOOR FAN MOTOR OVER CURRENT RELAY
(USE THE OPTIONAL PARTS : LOW AMBIENT PARTS)
51F4,5 2.0A
ITEM NO.
PR-5YC
PRH-5YA
PRH-5YA-L
PR-8YC
PRH-8YA
PRH-8YA-L
PR-15YC
PRH-15YA
PRH-15YA-L
PR-20YC
PRH-20YA
PRH-20YA-L
PR-10YC
PRH-10YA
PRH-10YA-L
COMPRESSOR OVER CURRENT RELAY 51C 26.0A 27.5A 31.0A
COMPRESSOR INTERNAL THERMOSTAT - 110˚C OFF 120˚C OFF 130˚C OFF
HIGH PRESSURE SWITCH 63H 2.94MPa OFF
FREEZE PROTECTOR 26L -2˚C IN
FROST PROTECTOR (ONLY PRH-YA,PRH-YA-L) 26D1,2 -12˚C IN, 6˚C OUT
INDOOR FAN MOTOR OVER CURRENT RELAY 51F1 2.3A 3.2A 3.6A
OUTDOOR FAN MOTOR OVER CURRENT RELAY 51F2 2.0A
OUTDOOR FAN MOTOR INTERNAL THERMOSTAT - 150˚C OFF
FUSE (CONTROL CIRCUIT) F 3.15A
FUSE (OPERATION CIRCUIT) F 3.15A
OUTDOOR FAN MOTOR OVER CURRENT RELAY
(USE THE OPTIONAL PARTS : LOW AMBIENT PARTS)
51F3 2.0A
DESCRIPTION
MODEL NAME
PARTS CODE
PR-5YC PRH-5YA PRH-5YA-L PR-8YC PRH-8YA PRH-8YA-L PR-10YC PRH-10YA PRH-10YA-L
K-Remote controller
PR- YC-K
-- -- --
PRH- YA-K ------
PRH- YA-LK -- - - --
Low temperature cooling
PR- YC
PAC-201LC - - PAC-202LC - - PAC-203LC - -
PRH- YA - PAC-201LC - - PAC-202LC - - PAC-203LC -
PRH- YA-L - - PAC-201LC - - PAC-202LC - - PAC-203LC
Pressure gauge
PR- YC
PAC001PG - - PAC002PG - - PAC003PG - -
PRH- YA - PAC001PG - - PAC002PG - - PAC003PG -
PRH- YA-L - - PAC001PG - - PAC002PG - - PAC003PG
Fin guard
PR- YC
PAC101FG - - PAC102FG - - PAC103FG - -
PRH- YA - PAC101FG - - PAC102FG - - PAC103FG -
PRH- YA-L - - PAC101FG - - PAC102FG - - PAC103FG
DESCRIPTION MODEL NAME
PARTS CODE
PR-15YC PRH-15YA PRH-15YA-L PR-20YC PRH-20YA PRH-20YA-L
Low temperature cooling
PR- YC
PAC-201LCX2(PCS)
- - PAC-201LCX2(PCS) - -
PRH- YA
-
PAC-201LCX2(PCS) - - PAC-201LCX2(PCS) -
PRH- YA-L
-
- PAC-201LCX2(PCS) - - PAC-201LCX2(PCS)
Pressure gauge
PR- YC
PAC001PGX2(PCS)
-- PAC001PGX2(PCS) - -
PRH- YA
-
PAC001PGX2(PCS) - - PAC001PGX2(PCS) -
PRH- YA-L
-
- PAC001PGX2(PCS) - - PAC001PGX2(PCS)
Fin guard
PR- YC
PAC104FG
- - PAC105FG - -
PRH- YA
-
PAC104FG - - PAC105FG -
PRH- YA-L
-
- PAC104FG - - PAC105FG
:Factory install
:Field install
