Using This Manual (1)
The symbols used in this manual are shown below.
Pr.*
....... Symbol indicating positioning parameter, zero point return
parameter and servo parameter item.
Da.*
....... Symbol indicating positioning data, start block data and condition
data item.
Md.*
....... Symbol indicating monitor data item.
Cd.*
....... Symbol indicating control data item.
(A serial No. is inserted in the * mark.)
Indication of values in this manual
•
The buffer memory address, error code and warning code are indicated in a
decimal value.
•
The X/Y device is indicated in a hexadecimal value.
•
The setting data and monitor data is indicated in a decimal or hexadecimal value.
An “H” attached at the end of the value indicates a hexadecimal value.
(Examples)
10 Decimal
10
H
Hexadecimal
