11 - 3
MELSEC-A
11 MANUAL CONTROL
Manual control auxiliary functions
Refer to section "3.3.4 Combination of AD75 main functions and auxiliary
functions" for details on "auxiliary functions" that can be combined with manual
control. Also refer to "Chapter 12 CONTROL AUXILIARY FUNCTIONS" for details
on each auxiliary function.
Carrying out manual control from peripheral devices
"JOG operation" and enabling/disabling of the "manual pulse generator operation"
can be executed from the AD75 software package test mode.
Refer to the AD75 Software Package Operating Manual for details on manual
control from the AD75 software package.
Monitoring manual control
Refer to section "5.6 List of monitor data" when directly monitoring the buffer
memory using the GPP function software package.
Also refer to the AD75 Software Package Operating Manual when monitoring with
the monitor functions of the AD75 software package.
