Mitsubishi A1SD75M3

2 - 3
MELSEC-A
2 SYSTEM CONFIGURATION
9
8
Cable
Manual pulse generator
Machine system input (switch)
· Near-point dog
· Limit switch
· External start signal
· Speed/position
changeover signal
· Stop signal
AD75TU
4
3
Personal
computer
Peripheral
device
2
(Refer to the AD75 Software Package
Operating Manual for details.)
AD75 software package
SW1IVD
-AD75P-E
SW0D5C
-AD75P-E
Motor
7
SSCNET cable
10
Servo
amplifier
corresponding
SSCNET*4
Motor
7
Terminal connector
Battery
Servo
amplifier
corresponding
SSCNET*4
