Chapter 3
SPECIFICATIONS AND FUNCTIONS
The various specifications of the AD75 are explained in this chapter.
The "General specifications", "Performance specifications", "List of functions",
"Specifications of input/output signals with PLC CPU", and the "Specifications of interfaces
with external devices", etc., are described as information required when designing the
positioning system.
Confirm each specification before designing the positioning system.
3.1 General specifications....................................................................................................3-2
3.2 Performance specifications............................................................................................3-3
3.3 List of functions ..............................................................................................................3-4
3.3.1 AD75 control functions......................................................................................3-4
3.3.2 AD75 main functions.........................................................................................3-6
3.3.3 AD75 auxiliary functions and common functions.............................................3-8
3.3.4 Combination of AD75 main functions and auxiliary functions.......................3-10
3.4 Specifications of input/output signals with PLC CPU..................................................3-12
3.4.1 List of input/output signals with PLC CPU .....................................................3-12
3.4.2 Details of input signals (AD75
PLC CPU) .................................................3-13
3.4.3 Details of output signals (PLC CPU
AD75) ...............................................3-14
3.5 Specifications of interfaces with external devices.......................................................3-15
3.5.1 Electrical specifications of input signals.........................................................3-15
3.5.2 Signal layout for external device connection connector................................3-16
3.5.3 List of input signal details................................................................................3-17
3.5.4 Interface internal circuit...................................................................................3-18
