12 CONTROL AUXILIARY FUNCTIONS
(2) "Indirectly specification data" configuration
The following AD75 buffer memory can store the "indirectly specification data
(positioning data No. 1 to 600)" corresponding to the "indirectly specification No.
(8001 to 8050)" on an axis basis.
Setting item
4549Positioning data No.(1 to 600)
Axis 1 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8050
Setting item
4501Positioning data No.(1 to 600)
Axis 1 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8002
Setting item
4500Positioning data No.(1 to 600)
Axis 1 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8001
Setting item
4799Positioning data No.(1 to 600)
Axis 1 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8050
Setting item
4751Positioning data No.(1 to 600)
Axis 1 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8002
Setting item
4750Positioning data No.(1 to 600)
Axis 2 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8001
Setting item
5049Positioning data No.(1 to 600)
Axis 1 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8050
Setting item
5001Positioning data No.(1 to 600)
Axis 1 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8002
Setting item
5000Positioning data No.(1 to 600)
Axis 3 indirectly specification data
Buffer memory
address
Indirectly speccification
No.8001
* Set to the AD75 using a sequence program or the AD75 software package.
