4 INSTALLATION, WIRING AND MAINTENANCE OF THE PRODUCT
4.1.2 Names of each part
The names of each AD75 part are shown below.
A1SD75M3
AX1
AX2
AX3
AX3AX2
RS-422
AX1
MODE
AX1
AX2
AX3
MODE
RS-422
AX1
AX2AX3
1SD75M3
A
For AD75M3 For A1SD75M3
D75M3
A
1) 17-segment LED
3) Mode switch
4) Module version label
2) Axis display LED
External device connection
connector (36-pin connector)
AX1: Axis 1
AX2: Axis 2
AX3: Axis 3
5) Peripheral device connection
connector
6)
7) SSCNET connection
connector
