Appendix 4 Outside Dimensions
Appendix 4.1 CPU Module
Appendix 4.1.1 A1SHCPU/A2SHCPU(S1) module
130 (5.12)
93.6 (3.69)
6.5 (0.26)
54.5 (2.15)
A1SHXPU
STOP
RUN
RESET
L.CLR
ERROR
RESET
RUN
MITHUBISHI
Unit : mm (in.
)
Appendix 4.1.2 A1SJHCPU module
A1SJHCPU
POWE R
ERROR
RUN
STOP
L.CLR RUN
RESETRESET
PULL
OUT
I/D0 I/D1 I/D2 I/D3 I/D4
330 (13.0)82 (3.23)
310 (12.2)
130 (5.12)
110 (4.33)
16.4
(0.65)
5
(0.2)
4-ø6 mounting screws
(M5
×
25)
Unit : mm (in.)
OUTPUT
5VDC 3A
INPUT
100-120VAC
200-240VAC
105VA
50/60Hz
INPUT
100-120/200-240VAC
(LG)
(FG)
WARNING
Hazardous
voltage.
