Mitsubishi A1SJH(S8) User Manual

2 - 16
SYSTEM CONFIGURATION2.
Temperature
regulating
module
A1S62RD3
For connecting to Pt100 (3-wire)
Temperature input, 2 channels
32
[32 special
points]
0.49 –
A1S62RD4
For connecting to Pt100 (4-wire)
Temperature input, 2 channels
32
[32 special
points]
0.39 –
A1S68TD Thermocouple input, 8 channels 32
[32 special
points]
0.32 –
A1S62TCTT-
S2
Transistor output, thermocouple input
2 channels/modules
PID control: ON/OFF pulse
32
[32 special
points]
0.19 –
A1S62TCTT
BW-S2
Transistor output, thermocouple input
2 channels/modules
PID control: ON/OFF pulse, wire breakage
detection function
32
[32 special
points]
0.28 –
A1S62TCRT-
S2
Transistor output, platinum temperature-mesuring
resistor input
2 channels/modules
PID control: ON/OFF pulse
32
[32 special
points]
0.19 –
A1S62TCRT
BW-S2
Transistor output, platinum temperature-mesuring
resistor input
2 channels/modules
PID control: ON/OFF pulse, wire breakage
detection function
32
[32 special
points]
0.28 –
A1S64TCTT-
S1
Transistor output, thermocouple input
4 channels/modules
PID control: ON/OFF pulse or 2 positioning control
32
[32 special
points]
0.33 –
A1S64TCTT
BW-S1
Transistor output, thermocouple input
4 channels/modules
PID control: ON/OFF pulse or 2 positioning control
Heater wire breakage detection function
32
[32 special
points]
0.42 –
A1S64TCRT-
S1
Transistor output, thermocouple input
4 channels/modules
PID control: ON/OFF pulse or 2 positioning control
32
[32 special
points]
0.33 –
A1S64TCRT
BW-S1
Transistor output, thermocouple input
4 channels/modules
PID control: ON/OFF pulse or 2 positioning control
Heater wire breakage detection function
32
[32 special
points]
0.42 –
A1S64TCTR
T
Transistor output, thermocouple/platinum
temperature-mesuring resistor input.
4 channels/modules
PID control: ON/OFF pulse or 2 positioning
control
32
[32 special
points]
0.33 –
A1S64TCTR
TBW
Transistor output, thermocouple/platinum
temperature-mesuring resistor input.
4 channels/modules
PID control: ON/OFF pulse or 2 positioning
control
Heater break detection function
32
[32 special
points]
0.39 –
Product Name Model Name Description
Number of occupied points
(points)
[I/O Assignment
Module Type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
