CAUTION
l
Handle halogen lamp bulbs with care.
The gas inside halogen lamp bulbs is high-
ly pressurized, so dropping, knocking, or
scratching a halogen lamp bulb can cause
it to shatter.
l
Never hold the halogen lamp bulb with a
bare hand, dirty glove, etc.
The oil from your hand could cause the
bulb to break the next time the fog lamps
are operated.
If the glass surface is dirty, it must be
cleaned with alcohol, paint thinner, etc.,
and refit it after drying it thoroughly.
Daytime running lamps*
E01011200055
1. Pull
the lamp cover (A) to the direction of
the arrow to remove it.
2. Remove
the screws (B), and then remove the
lamp unit.
3. Turn the bulb (C) anticlockwise to remove it.
4. While
holding down the tab (D), pull out the
socket (E).
5. To
install the bulb, perform the removal
steps in reverse.
Maintenance
8-30
8
