Mitsubishi CP710E User Manual

10
4. Connection with external equipment (VIDEO/S-VIDEO)
22
22
2 Connection with VIDEO signal, S-VIDEO (Y/C separate VIDEO) signal equipment
When connecting the unit with another equipment, make sure to set the power of each equipment to "OFF".
S-VIDEO
REMOTE
AC LINE
VIDEO
1 2
,,
,,
PUSH
To VIDEO IN terminal
VIDEO ( )
To VIDEO OUT
terminal
VCP
VIDEO signal
equipment
S-VIDEO
REMOTE
AC LINE
VIDEO
1 2
To S-VIDEO IN terminal
S-VIDEO ( )
To S-VIDEO OUT terminalVCP
S-VIDEO signal equipment
VIDEO signal
S-VIDEO signal
