Mitsubishi Diamond Pro 750SB User Manual

4-2
1. Adjustment & Inspection Tools
(A) Color Analyzer (B) Signal Generator CHROMA 2235 or compatible
(C) Multi Meter (D) Hi-Voltage Probe
(E) Convergence Meter (F) Degaussing Probe
(G) Power Meter
2. Timing Table (Factory Mode –18 Modes)
MODE RESOLUTION H-SYNC EREQ. V-SYNC FREQ H . POLARITY V . POLARITY
1 VGA400 31.4KHz 70Hz - +
2 VGA640*480 31.4KHz 60Hz - -
3 640*480(75) 37.5KHz 75Hz - -
4 640*480(85) 43.2KHz 85Hz - -
5 800*600(75) 46.8KHz 75Hz + +
6 MACII 49K 49.7KHz 75Hz - -
7 800*600(85) 53.6KHz 85Hz + +
8 1024*768(75) 60.0KHz 75Hz + +
9 1280*1024(60) 64.0KHz 60Hz + +
10 1024*768(85) 68.6KHz 85Hz + +
11 1280*1024(75) 79.9KHz 75Hz + +
12 1280*1024(85) 91.1KHz 85Hz + +
13 1600*1200(75) 93.7KHz 75Hz + +
14 1024*768(60) 48.3KHz 60Hz - -
15 800*600(60) 37.8KHz 60Hz + +
16 MACII 35K 35.0KHz 67Hz - +
17 MAC 1152*870 68.7KHz 75Hz - -
18 VGA720*400(70) 31.5KHz 70Hz - +
3. Normal Condition Definition
(A) Input AC Voltage 110V/60Hz.
(B) Warm up time minimum 30 minutes.
(C) Full White Pattern.
(D) All VR’s adjust to Center Position.
(F) Color temp 9300K

Mitsubishi Diamond Pro 750SB Specifications

General

Screen Size	17 inches
Display Type	CRT
Max Resolution	1600 x 1200
Refresh Rate	85 Hz
Dot Pitch	0.25 mm
Horizontal Refresh Rate	30-96 kHz
Vertical Refresh Rate	50-160 Hz
Input Signal	Analog RGB
Response Time	Not applicable
