Features and controls
3-127
3
History
N00502500033
It is possible to change the range for which historical data are
shown in the graphs.
1. Press the “ ” function button, align the cursor with the
desired setting, and press the “SELECT” function button.
• 3 hours: The average value is added to the graph every 6
minutes. Data for a maximum of 3 hours are shown in
the graph.
• 12 hours: The average value is added to the graph every
24 minutes. Data for a maximum of 12 hours are shown
in the graph.
OTE
● The initial (default) setting is “3 hours”.
2. The monitor will show “The setting is progressing” while
the setting change is in progress.
When the setting change has been completed successfully,
a tone will sound once and the monitor will return to the
“History” display.
If the setting change is not successful, the monitor will
show “The setting failed.” then return to the “History”
display.
