Features and controls
3-133
3
3. Press the “ ” function button, align the cursor with the
correct zone code number, and press the “SELECT” func-
tion button.
When the setting change has been completed successfully,
the tone will sound once and the monitor will return to the
“Compass setting” display.
If the setting change is not successful, the monitor will
show “The setting failed” and then return to the “Compass
setting” display.
OTE
● The correct zone code is memorized even if the battery is
disconnected.
Compass calibration
N00534400077
1. Display “Compass calibration” on the monitor in accor-
dance with “Basic operation” (see page 3-109), align the
cursor with it, and press the “SELECT” function button.
CAUTION
!
● Operate the compass calibration only when the vehi-
cle is in a safe, open area.
