Seat and restraint systems
2-57
2
The side air bag and curtain air bag ARE NOT
DESIGNED TO DEPLOY when …
The side air bag and curtain air bag are not designed to deploy
in situations where they cannot provide protection to the occu-
pants. Some typical situations are shown in the illustrations.
Because the side air bags and curtain air bags do not protect the
occupants in all types of collisions, be sure to always wear your
seat belts properly.
Head-on collision
Rear end collision to you vehicle
Pitch end over end
