F9Q ENGINE
–
Specifications
1
1A-1-3
Item
Nm
Camshaft and vacuum pump
Engine hanger bolt
13
±
1
Glow plug
15
±
1
Camshaft position sensor screw
8.8
±
1.5
Cylinder head cover bolt
12
±
1
Bearing cap bolt
20
±
2
Oil pan and oil pump
Oil pan bolt
14
±
1
Oil pump bolt
25
±
2
Cylinder block front plate bolt
15
±
1.5
Piston
Connecting rod cap bolt
50
±
5
Cylinder block
Flywheel bolt
55
±
5
Bearing cap bolt
65
±
6
PWEE0001-A
E
Mar
. 2001
Mitsubishi Motors Corporation
Revised
9
11
