F9Q ENGINE -
Piston
11A-13-1
13. PISTON
REMOVAL AND INSTALLATION
REN0195
2
3
4
8
5
6
7
10
11
9
50
±
5Nm
1
Removal steps
1. Connecting rod bolt
A
A
"
2. Connecting rod cap
3. Connecting rod lower bearing
4. Connecting rod upper bearing
"
B
A
5. Piston ring No. 1
"
B
A
6. Piston ring No. 2
7. Oil ring
A
B
""
A
A
8. Snap ring
A
B
""
A
A
9. Piston pin
"
C
A
10. Piston
"
C
A
11. Connecting rod
PWEE0001
E
Jun. 2000Mitsubishi Motors Corporation
