Mitsubishi FX1N-14MT-ESS/UL User Manual

FX1N Series Programmable Controllers Introduction 1.
1-8
1.2 Model Name
*1. The FX
0N-
40ET-DSS and FX
0N-
40ER-DSS FX
0N
series extension units do not have UL certi-
fication.
Table 1.7 :Notes on model name
Ref. Description Ref. Description
A)
PLC type: FX
1N
E)
Features
B)
Total number of I / O channels
Omit AC, Japanese spec.
C)
Unit type
D DC Japanese spec.
M MPU - main unit DS DC World spec, CE & UL registered.
E Powered extension unit DSS DC World spec, DC source transistor, CE & UL registered.
EX Extension block, input E AC, Japanese spec.
EY Extension block, output ES AC, World spec, CE registered.
D)
Output type
ESS AC World spec, DC source transistor, CE registered.
RRelay UA1 AC Power Supply, AC inputs, CE registered.
TTransistor
F)
UL UL registered
STriac (SSR)
FX
1N
-24MR-DS /

C)
A)
B)
E)
D)
F)

Mitsubishi FX1N-14MT-ESS/UL Specifications

General

PLC Series	FX1N
Number of I/O Points	14
Input Points	8
Output Points	6
Output Type	Transistor
Supply Voltage	100-240V AC
Power Supply	Built-in
Type	PLC
Communication Ports	RS-422
Certification	UL
Program Memory	8K steps
