FX1N Series Programmable Controllers Introduction 1.
1-5
1
2
3
4
5
6
7
Table 1.4: Special function blocks
MODEL DESCRIPTION
DIMENSIONS
mm (inches)
MASS
(WEIGHT)
kg (lbs)
FX
0N
-3A Analog / Digital converter 43 (1.70)
90 (3.5)
87 (3.43)
0.2 (0.44)
FX
2N
-5A Analog / Digital converter 55 (2.17) 0.3 (0.66)
FX
2N
-2DA Digital to analog converter
43 (1.70) 0.2 (0.44)
FX
2N
-2AD Analog to digital converter
FX
2N
-4DA Digital to analog converter
55 (2.17)
0.3 (0.66)
FX
2N
-4AD Analog to digital converter
FX
2N
-4AD-PT PT 100 probe interface
FX
2N
-4AD-TC Thermo-couple interface
FX
2N
-8AD Analog input interface 75 (2.96) 75 (2.96)
FX
2N
-2LC Temperature Control 55 (2.17)
87 (3.43)
FX
2N
-16LNK-M
MELSEC I/O LINK
Remote I/O system master
43 (1.70)
0.5 (1.1)
FX
2N
-16CCL-M CC-Link master 0.4 (0.88)
FX
2N
-32CCL CC-Link interface 0.2 (0.44)
FX
2N
-64CL-M CC-Link/LT master 0.15 (0.33)
FX
2N
-32ASI-M AS-interface master 55 (2.17) 0.2 (0.44)
