FX1N Series Programmable Controllers Power Supply 4.
4-3
1
2
3
4
5
6
7
4.4 Power Requirements
*1
Includes the input current (5 or 7mA per point).
*1 Includes the input current (5 or 7mA per point).
Table 4.1 :AC Power Supply Units
FX
1N
-14M FX
1N
-24M FX
1N
-40M FX
1N
-60M
Power supply 100 - 240V AC +10%, -15%, 50-60Hz
Max. allowable momentary power
failure period
10ms; if less than 10ms, the PLC will continue operation.
If 10ms or more, the PLC will shut down
Fuse (size) rating 250V 1A 250V 3.15A (3A)
In-rush current
100V AC - Max. 30A for 5ms
200V AC - Max. 50A for 5ms
Power consumption 29W
*1
30W
*1
32W
*1
35W
*1
24V DC Service Supply 400 mA
Table 4.2 :DC Power Supply Units
FX
1N
-14M FX
1N
-24M FX
1N
-40M FX
1N
-60M
Power supply 24V DC +20% ~ 12V DC -15% (28.8 ~ 10.2V DC)
Max. allowable momentary power
failure period
5 ms; If less than 5 ms, the PLC will continue operation.
If 5 ms or more, the PLC will shut down
Fuse (size) rating 125 V 3.15A
In-rush current
24V DC - Max. 25A for 1ms
12V DC - Max. 22A for 0.3ms
Power consumption
*1
13W 15W 18W 20W
