FX1N Series Programmable Controllers Installation Notes 3.
3-5
1
2
3
4
5
6
7
3.3 General Specifications
*1 Perform dielectric withstand voltage and insulation resistance tests at the stated voltage
between each terminal and the main unit’s ground terminal.
Item Description
Operating Temperature 0 to 55 °C (32 to 131 °F)
Storage Temperature -20 to 70 °C (-4 to 158 °F)
Operating Humidity 35 to 85% Relative Humidity, No condensation
storage Humidity 35 to 90% Relative Humidity, No condensation
Vibration Resistance
- Direct Mounting
Conforms to EN 68-2-6; 10 - 57 Hz: 0.075 mm Half Amplitude
57 - 150 Hz: 9.8 m/s
2
Acceleration
Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration Resistance
- DIN rail Mounting
Conforms to EN 68-2-6; 10 - 57 Hz: 0.035 mm Half Amplitude
57 -150 Hz: 4.9 m/s
2
Acceleration
Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Shock Resistance
Conforms to EN 68-2-27: 147m/s
2
Acceleration, Action Time: 11 ms
3 times in each direction X, Y, and Z
Noise Immunity 1000 Vp-p, 1microsecond, 30 - 100 Hz, tested by noise simulator
Dielectric Withstand
Voltage
AC PSU: 1500 V AC > 1 min., tested between each terminal with ground terminal
*1
DC PSU: 500 V AC > 1 min., tested between each terminal with ground terminal
*1
Insulation Resistance
5 M
Ω
> at 500 V DC, tested between each terminal with ground terminal
*1
Ground Grounding resistance 100
Ω
or less
Certification UL/cUL (UL508)
EC Directive EMC (EN61000-6-2, EN50081-2), LVD (EN61010-1)
