Mitsubishi FX1N-40MR-DS User Manual

FX1N Series Programmable Controllers Installation Notes 3.
3-15
1
2
3
4
5
6
7
2) Handle the crimp terminal of the following size when 2 wires are used per terminal. Refer to
Figure 3.8 for installation instructions.
Figure 3.6:Crimp Terminal for M3.5 Screws
Figure 3.7:Crimp Terminal for M3 Screws
Figure 3.8:Installing 2 Wires Per a Terminal
6.8 mm (0.27" )
or less
φ
3.7 (0.15")
6.8 mm (0.27")
or less
φ
3.7 (0.15")
6.0 mm or more 6.0 mm or mor
e
6.2 mm (0.24" )
or less
φ
3.2 (0.13")
6.2 mm (0.24")
or less
φ
3.2 (0.13")
6.3 mm or more
6.3 mm or more
Terminal
Terminal
screw
Crimp
terminal

Mitsubishi FX1N-40MR-DS Specifications

General

Brand	Mitsubishi
Model	FX1N-40MR-DS
Category	Controller
Language	English
