FX1N Series Programmable Controllers Introduction 1.
1-11
1
2
3
4
5
6
7
*1 Available for use with FX
1N
version 2.00 or later.
*2 When using the FX
1N
-EEPROM-8L with an expansion board in group C, only the loader
function (transfer program) can be used. Remove it from the PLC after operating the
loader function and attach the top cover into the PLC.
*3 GOT-F900 Series can connect via an FX
1N
-232-BD to the FX
1N
PLC.
*4 When supplying 24V DC power source to the FX
1N
main unit, only the FX
0N
series
powered extension unit (DC power supply type) can connect.
When supplying 12V DC power source to the FX
1N
main unit, the powered extension unit
and special function blocks cannot connect to it.
*5 FX
1N
series PLC cannot connect together with an FX
2N
-32ASI-M and FX
2N
-16CCL-M.
An FX
2N
-32ASI-M module cannot be attached to an FX
1N
series PLC that is using an
FX
2N
-16CCL-M module. Only one FX
2N
-32ASI-M module can be connected to the PLC.
