Mitsubishi H2i-R2-1 User Manual

H2i-R2-6
PURY-HP-T(S)KMU,-Y(S)KMU (September 2014)
© 2014 Mitsubishi Electric US, Inc.
1. SPECIFICATIONS
Model PURY-HP192TSKMU-A-H
Power source 3-phase 3-wire 208 / 230V ±10% 60Hz
Cooling capacity (Nominal) *1 (208 / 230V)
Btu/h 192,000
kW 56.3
Power input kW 15.86 *4
Current input A 48.9 / 44.2 *4
Temp. range of cooling *3
Indoor W.B. 59 ~ 75° F(15 ~ 24° C)
Outdoor D.B. 23 ~ 115° F (-5 ~ +46° C) *5
Heating capacity (Nominal) *2 (208-230V)
Btu/h 215,000
kW 63.0
Power input kW 18.52 *4
Current input A 55.9 / 50.5 *4
Temp. range of heating *3
Indoor D.B. 59~81°F(15~27°C)
Outdoor W.B. -13~60°F(-25~15.5°C)
System Compressor Operating Range Heating: 6-100%
Indoor unit
connectable
Total capacity 50~150 % of outdoor unit capacity
Model / Quantity P06~P96 / 1-48
Sound pressure level (measured in anechoic room) dB <A> 61.0
Refrigerant piping diameter
from Twinning Kit to Indoor
Units
Liquid (High Pressure) In. (mm) 7/8”(22.2) Brazed
Gas (Low Pressure) In. (mm) 1-1/8”(28.58) Brazed
Set Model
Model PURY-HP96TKMU-A-H PURY-HP96TKMU-A-H
Fan
Type x Quantity Propeller fan x 1 Propeller fan x 1
Airow rate
CFM 6,200 6,200
m3 / min 175 175
L/s 2,920 2,920
Control , Driving mechanism Inverter-control, Brushless DC motor Inverter-control, Brushless DC motor
External static pressure *6 0 in.WG (0 Pa) *6 0 in.WG (0 Pa) *6
Compressor
Type x Quantity Inverter scroll hermetic compressor x 1 Inverter scroll hermetic compressor x 1
Manufacturer AC&R Works, MITSUBISHI ELECTRIC CORP. AC&R Works, MITSUBISHI ELECTRIC CORP.
Starting method Inverter Inverter
Lubricant MEL32 MEL32
External nish
Pre-coated galvanized steel sheet
<MUNSELL 5Y 8/1 or similar>
Pre-coated galvanized steel sheet
<MUNSELL 5Y 8/1 or similar>
External dimension H x W x D
In. 64-31/32 x 48-1/16 x 29-15/16 64-31/32 x 48-1/16 x 29-15/16
mm 1,650 x 1,220 x 760 1,650 x 1,220 x 760
Protection
devices
High pressure protection
High pressure sensor, High pressure switch at
4.15MPa (601 psi)
High pressure sensor, High pressure switch at
4.15MPa (601 psi)
Inverter circuit (COMP. / FAN) Over-current protection Over-current protection
Fan Motor Thermal switch Thermal switch
Minimum Circuit Ampacity (MCA) A 60 / 54 60 / 54
Recommended Fuse/Breaker Size A 65 65
Maximum Fuse Size A 80 80
Refrigerant
Type x original charge R410A x 26 lbs + 1oz (11.8kg) R410A x 26 lbs + 1oz (11.8kg)
Control LEV and HIC circuit
Net weight lbs (kg) 552 (250) 552 (250)
Heat exchanger Salt-resistant cross n & copper tube Salt-resistant cross n & copper tube
Refrigerant piping diameter
from Module to Twinning Kit
Liquid (High Pressure) In. (mm) 3/4”(19.05)Brazed 3/4”(19.05)Brazed
Gas (Low Pressure) In. (mm) 7/8”(22.2)Brazed 7/8”(22.2)Brazed
Defrosting method Auto-defrost mode (Reversed refrigerant cycle)
Drawing
External KJ94G492
Wiring KE94C883 KE94C883
Standard attachment
Document Installation Manual
Accessory Details refer to External Drw
Optional parts
Outdoor Twinning kit: CMY-Y100CBK2
Joint: CMY-Y102SS-G2,CMY-Y102LS-G2,CMY-Y202S-G2,CMY-R160C-J
Main BC controller: CMB-P108,1010,1013,1016NU-GA,1016NU-HA
Sub BC controller: CMB-P104,108NU-GB,CMB-P1016NU-HB
Remark
Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and
other items shall be referred to the Installation Manual.
*3 Harsh weather environments may demand performance enhancing equipment.
Ask your Mitsubishi Electric representative for more details on your region.
*4 For details on the electrical data needed for installing these units,
see the H2i R2-Series System Design section.
*5 For details on extended ambient cooling operation range down to -10°FDB (-23°CDB),
see Low Ambient Cooling Kit information.
*6 External static pressure is adjustable via dipswitch setting
(0.12 in.WG, 0.24 in.WG / 30Pa, 60Pa).
Note: *1 Nominal cooling conditions *2 Nominal heating conditions Unit converter
Indoor:
80degF D.B./ 67degF W.B. 70degF D.B. kcal =kW x 860
(26.7degC D.B./ 19.4degC W.B.) (21.1degC D.B.) BTU/h =kW x 3,412
Outdoor: 95degF D.B. (35degC D.B.)
47degF D.B./ 43degF W.B.
(8.3degC D.B./ 6.1degC W.B.)
cfm =m
3
/min x 35.31
lb =kg / 0.4536
Pipe length: 25ft.(7.6m) 25ft.(7.6m)
* Above specification data is subject to rounding
variation.
Level difference: 0ft.(0m) 0ft.(0m)
* Due to continuing improvement, above specifications may be subject to change without notice.
