No.9
INSPECTION RECORD SHEET
Remark
A
pproved
by
Checked
by
Measured
by
Measuring Positions
Standard
Measured Values
1
Before Adjustment
No.
Service Hours (h)
2
3
Valve Opening Pressure
After Adjustment
Engine Model
Serial No.
Valve Opening Pressure
L
Inspection
Point
Unit
Measurement of Valve Opening Pressure of Fuel Injection
Nozzle
Date
Company
MPa
{kgf/cm
2
}
[psi]
Standard
13.73 to 14.73
{140 to 150}
[1992 to 2134]
Nominal Value
Valve Opening
Pressure
13.73
{140}
[1992]
Supplement-10
249
251
