1.7 Electrical system
Table 2-7 Maintenance service data table - Electrical system(1 / 3) Unit: mm [in.]
Inspection point Nominal Standard Limit Remark
Starter
M000T60481
(12V-1.2kW)
Pinion clearance
0.5 to 2.0
[0.0197 to 0.0787]
Brush length
16.5
[0.650]
10.0
[0.394]
Brush spring load
20.58 N
{2.10 kgf}
[4.6 lbf]
17.5 to 23.7 N
{1.78 to 2.42 kgf}
[3.92 to 5.34 lbf]
6.86 N
{0.70 kgf}
[1.54 lbf]
Commutator radial runout
0.03
[0.0012]
0.10
[0.0039]
Commutator outside diameter
ø 29.4
[1.158]
ø 28.8
[1.134]
Depth of undercuts between segments
0.75
[0.030]
0.5 to 1.0
[0.0197 to 0.0394]
0.2
[0.0079] or less
No-load
characteristics
Terminal voltage
11 V
Current
90 A or less
Rotation speed
2500 min
-1
or more
Starter
M001T68381
(12V-1.7kW)
Pinion clearance
0.5 to 2.0
[0.0197 to 0.0787]
Brush length
16.5
[0.650]
10
[0.394]
Brush spring load
20.58 N
{2.10 kgf}
[4.6 lbf]
17.5 to 23.7 N
{1.78 to 2.42 kgf}
[3.92 to 5.34 lbf]
6.86 N
{0.70 kgf}
[1.54 lbf]
Commutator radial runout
0.03
[0.0012]
0.10
[0.0039]
Commutator outside diameter
ø 29.4
[1.158]
ø 28.8
[1.134]
Depth of undercuts between segments
0.75
[0.030]
0.5 to 1.0
[0.0197 to 0.0394]
0.2
[0.0079] or less
No-load
characteristics
Terminal voltage
11 V
Current
110 A or less
Rotation speed
2400 min
-1
or more
