Eng lis h- 2
Fe atures
Wide-range Color Temperature Adjustment Page 34
The display color temperatures can be adjusted from 2,600 K to 10,000 K. Such a wide range adjustment is important for industries
such as broadcasters and food retailers where color accuracy and esh tones are critical.
Tiling Capability with Frame compensation Page 39
Up to 25 panels (5 wide x 5 high) can be combined to create a single large image (i.e., video wall) or other high-impact signage. A
frame compesation function is incorporated to compensate the width of panel bezels so that images are displayed with the utmost
accuracy.
PiP, PoP and Side-by-side Pages 37 and 43
Picture-in-Picture and Picture-out-of-Picture are available when you want to display video content from a video input source in the
sub picture and display the PC input source in the main picture, and vice versa.
The native resolution as high as 1
x can display these two input sources in the Side-by-side mode, ideal for broadcasting
and video-conferencing applications.
Programmable Scheduling Function Pages 28, 29 and 38
The monitor s operating schedule can be programmed for up to seven different scheduled time intervals by time, day of the week
and input port. This allows video content from different inputs to be displayed on certain monitors within the same installation
according to the schedule, and extends the monitor s life and saves the power by turning it off during those hours or days it i
s not in
use.
Screen-saver Functions Page 40
To reduce image persistence and maximize the panel life in demanding signage applications, the LDT Series is equipped with four
screen-saver functions.
GAMMA
COOLING FAN
BRIGHTNESS
MOTION
Side Border Color Select Page 40
When the 4:3 screen is displayed, the side border color can be selected from black, gray and white.
Power-on Delay Page 39
For installations employing numerous monitors, the power-on delay function c an power up the monitors sequentially with delay
between 2-50 seconds after the power is applied. Using this function can prevent inrush current problems and reduce the overall
electrical load requirements when a single power supply is used.
Flexible Landscape & Portrait Positioning Page 15
Designed to enhance for heat dissipation and long-term reliability in both landscape (horizontal) and portrait (vertical) positio ns.
Closed Caption Page 39
You can display captions.
When closed-caption video signals are input, you can select to display or hide the captions on the screen.
This monitor is compliant with EIA-608-A.
