2
*2 This index indicates the degree to which conductive material is generated in
terms of the environment in which the equipment is used. Pollution level 2 is
when only non-conductive pollution occurs. A temporary conductivity caused
by condensing must be expected occasionally.
*3 Do not use or store the programmable controller under pressure higher than
the atmospheric pressure of altitude 0m. Doing so may cause malfunction.
When using the programmable controller under pressure, please consult
your local Mitsubishi Electric representative.
*4 When an A series extension base unit (A52B, A55B, A58B, A62B, A65B,
A68B) is used in the system, the following specifications apply.
Frequency Acceleration Amplitude Sweep count
Under
intermittent
vibration
10 to 57Hz - 0.075mm
10 times each in
X, Y, Z directions
57 to 150Hz 9.8m/s
2
-
Under
continuous
vibration
10 to 57Hz - 0.035mm
-
57 to 150Hz 4.9m/s
2
-
